€3.800.00
· Up to 24 HDDs, 2000 channels
· 18 1080P decoding
· Input 512M, output 400M
· Recording channel 256, forwarding channel 200
Available on backorder
· Video input bandwidth 512M, output bandwidth 400M;
Video recording channel 256 / Forwarding channel 200 ( Disable face recognition)
· Support local video storage
· Support NTP function
· Support RAID 0/1/5/6/10/50/60
· Able to operate the configuration and monitor the status of disk and RAID group by adopting visible management UI
· Able to conduct human, vehicle, attendance, device and access control
· Able to conduct face search
· Able to conduct early warning linkage
| Date | Title | Type | Download |
|---|---|---|---|
| 2021-12-09 | K2000 |  |
| Main Functions | |
| Device management | Support management of IP cameras, NVRs and network video encoder/decoders |
| Support configuration of device information and account authority | |
| Support detection of device status | |
| Live view | Support auto switch of main and sub stream, live windows can be drag to form a large single window. Live windows can be divided into 4/6/8/10 mode or 1-5/1-7 consist of main/sub stream. The number of screens per row/column can be customized up to 64 as well. Supports electronic zoom, image capture. Supports switch by single channel, group or all channels, users can customize switch plan |
| PTZ control | Support pan tilt and zoom control including 8 directions control, zoom/aperture/focus settings, preset settings, wiper control and 3D positioning |
| Video management | Support recording template that users can easily arrange start time, end time, week time and recording duration |
| Video playback | Support device storage/centralized storage/local storage and multiple method for searching video |
| Support timing video recording, playback, video download, image capture, multi-speed playback in server | |
| Video wall | Support video wall template configuration and video switch |
| Event management | Support multiple alarm types and linkage of alarm input and output interfaces. Events can be prioritized by importance |
| Intelligent analysis | Support linkage of VCA functions |
| Alarm linkage | Support linkage of alarm output, video recording, sound, pop on video wall, e-map, image capture and preset of PTZ |
| User management | Support user account management like setting authority and expiration time |
| Log management | Support recording log like adding, deleting and modifying for each module independently |
| Support searching and exporting log information for each module | |
| E-map | Support using super high-resolution picture as e-map background |
| Support google GIS map and different surveillance icons overlay on maps | |
| Two-way audio | Support two-way audio to devices and volume is adjustable |
| Decoding | Support 2 HDMI& 1VGA output interfaces and 18 1080P decoding |
| Support 3 optional decoding cards and up to 18 screens output | |
| Compatible devices | Support access of IP cameras, NVRs, centralized storage and servers. |
| Support 400 channels access via ONVIF and 1100 channels via Tiandy private protocal. Support 2000 channels via Tiandy private protocal only. |
|
| Group management | Support adding, modifying, searching and deleting the organization structure and offical authority |
| Face management | Support up to 50 face recognition cameras connection |
| Support up to 5000 face pictures each library | |
| Support analysis and statistics of face alarm | |
| Support to search picture by picture and search face picture by time or name | |
| Specifications | |
| CPU | 64-bit multicore processor |
| Memory | 24GB (3×8GB, 4 memory slots), maximum 64G |
| OS HDD | 32G SSD |
| Network interface | 4xRJ45 self-adaptive 10/100/1000 Mbps network interfaces |
| Data HDD | Up to 24 disks |
| HDD type | 2.5″ or 3.5″ SATA |
| HDD capacity | 4/6/8TB enterprise HDD 4/6/8/10TB surveillance HDD |
| Interfaces | 2 USB 2.0 ports in front panel, 2 USB 3.0 ports in rare panel 2 HDMI, 1 VGA 2 RS485, 1 RS232 8 alarm input, 4 alarm output |
| RAID | RAID 0/1/5/6/10/50/60 |
| General | |
| Power supply | AC100V～AC240V, 50Hz/60Hz |
| Power consumption | Rated power: 800W Peak power: 500W Average power: 300W |
| Working temperature | 0℃~40℃ |
| Working humidity | 10％～90％(RH) |
| Dimensions | 542mm(L)×446.6mm(W)×173.8mm(H) |
| Software | |
| Management platform | WEB GUI |
| Management software | IPC access management, Recording file management, alarm linkage |
| IPC channels | 2000 |
| User account | 100 |
| Middleware adapter | 1 |
| Middleware number | 1 |
| Icon overlay on map | 1000 |
| Person information | 10000 |
| Face recognition camera access Maximum | 50 |
| ANPR camera access Maximum | 25 |
| Access control PAD (ID card) Maximum | 70 |
| Face turnstile Maximum | 24 |
| Log record 500,000 per 90 days | 90 days |
| Alarm record 5,000,000 per 90 days | 90 days |
| Face Pad record 3,000,000 per 90 days | 90 days |
| Face capture record | 2,000,000 per 90 days |
| Attendace record(1000 people) | 365,000 per year |
| Dynamic Statistics * The following listed numbers are peak performance, they may not be supported at the same time |
|
| GPS location reported | 10/s |
| Access users | 50 |
| Online users | 100 |
| Access APP | 100 |
| Alarm go off per second | 8 |
| Picture performance | Send/Receive 25 pictures/S Less than 550K each picture, up to 18,000 pictures every day |
| Video performance (Picture and video storage in same time) | |
| Video storage capability | Up to 180 channels (2Mbs, H.265) |
| Video forwarding capability | Up to 180 channels forwarding and decoding combined (2Mbs, H.265) |
| Decoding capability | Up to 80 channels in main stream (1080P, 2Mbs, H.265), 100 channels in substream |
| Video switching | Up to 80 channels in main stream (1080P, 2Mbs, H.265), 55 channels in substream |
| Video performance (Video storage only) | |
| Video storage capability | Up to 256 channels (2Mbs, H.265) |
| Video forwarding capability | Up to 200 channels forwarding and decoding combined (2Mbs, H.265) |
| Decoding capability | Up to 144 channels in main stream, 384 channels in substream (1080P 2Mbs H265) |
| Video switching | Up to 40 channels in main stream, 384 channels in substream (1080P 2Mbs H265) |
