€80.00
• Starlight Ultra Low Light 0.002lux
• Up To 5MP, 2592×1944
• Cable Free Design
• S 265 Compression
14 in stock
| Camera | |
| Image Sensor | 1/2.8″ CMOS |
| Core Processor | ARM7 Architecture |
| Operating System | Embedded Linux |
| Signal System | PAL/NTSC |
| Min. Illumination | Color: 0.002Lux(F1.6,AGC ON) |
| B/W: 0.001Lux(F1.6,AGC ON); 0Lux with IR | |
| Shutter Time | 1s～1/100000s |
| Lens | 4mm, Angle of View: 81.5° |
| Lens Mount | φ 12 |
| Auto Iris | N/A |
| Day& Night | Dual IR Cut Filter with Auto Switch |
| WDR | 120 dB |
| DNR | 3D DNR |
| S/N Ratio | >60dB |
| Compression Standard | |
| Video Compression | S 265/H.265/H.264H/H.264M/H.264B/MJPEG |
| Video Bit Rate | 32Kbps~16Mbps |
| Image | |
| Max. Image Resolution | 2592×1944 |
| Frame Rate | PAL：2592*1944@18fps，2560*1920@20fps，2592*1520@25fps，1440P@25fps，QXGA@25fps，1080P@25fps ，960P@25fps，720P@25fps，640*360@25fps,4CIF@25fps，2CIF@25fps，CIF@25fps |
| NTSC：2592*1944@18fps，2560*1920@20fps，2592*1520@25fps ，1440P@25fps，QXGA@30fps，1080P@30fps，
960P@30fps，720P@30fps，640*360@30fps,4CIF@30fps，2CIF@30fps，CIF@30fps |
|
| Triple Stream | Mainstream:2592×1944 |
| Substream:D1(704×576) | |
| 3rd stream:CIF(352×288) | |
| Image Settings | Brightness, Saturation, Contrast, Sharpness, Image Enhancement |
| Flip Mode Adjustable by Client Software or Web Browser | |
| HLC | Y |
| Smart Defog | Y |
| Corridor Format | Y, Available for 720P and Above |
| EIS | Y |
| ROI | 4 Zones |
| Privacy Mask | 4 Zones |
| Picture Overlay | 200 × 200, BMP 24bit, Zone Configurable |
| OSD | Size:16×16, 32×32, 24×24, 48×48, 64×64, 96×96 |
| Letters, Week, Date, Time, Total 5 Regions | |
| Network | |
| Browser | IE,Chrome,Firefox, Safari, Plug-in Free |
| Network Storage | FTP |
| NTP | Y |
| ANR | Y(Auto store video in SD card when NVR disconnected, and upload video to NVR when resumed connection(Only Support Tiandy ANR NVR) ) |
| Video Analytics(VCA) | Tripwire/Double Tripwire/Perimeter/Object Abandon |
| Object Lost/Running/Loitering/Parking/Crowd/Video Abnormal Detection | |
| Alarm Trigger | Motion Detection/IP Conflict/MAC Conflict/Mask Alarm |
| Protocols | IPv4/IPv6/HTTP/FTP/SMTP/UPnP/SNMP |
| DNS/DDNS/NTP/RTSP/TCP/UDP/DHCP | |
| User Permission | 4 Level/8 Users |
| Remote Connection | 7Users Access at the Same Time |
| System Compatibility | ONVIF (Profile S),P2P, SDK, CGI |
| Interface | |
| Audio Input | N/A |
| Audio Output | N/A |
| Ethernet | 1-ch RJ45 10M / 100M |
| Alarm Input | N/A |
| Alarm Output | N/A |
| Video Output | N/A |
| On-board Storage | MicroSD Card Slot, up to 128GB |
| Reset | Y |
| General | |
| Language | English,Spanish,Korean,Italian,Turkish,Thai,Russian |
| Polish,French,Traditional Chinese,Simplified Chinese | |
| Operating Conditions | -35℃～60℃(IR OFF) /-35℃～40℃(IR ON), 0～95% RHG |
| Power Supply | DC 12 V ± 10%, PoE (802.3af) |
| Power Consumption | Max. 5W(IR OFF) (ICR Instant Switch 10W) |
| Max. 7W(IR ON) | |
| Circuit Protection | TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V) |
| Impact Protection | IP67 |
| IR Range | 25m |
| IR LEDs | 2pcs Array |
| Dimensions | 189mm×70mm×70mm |
| Weight | 0.6KG (IP Camera Only); 0.7KG (with Packing Box) |
