€150.00
• Up to 5-channel input
• Incoming Bandwidth 50Mbps
• Outgoing Bandwidth 40Mbps
• Support Wi-Fi matching of Tinady Wi-Fi IP cameras
| Date | Title | Type | Download |
|---|---|---|---|
| 2021-09-10 | TC-R3105 Spec-I-B-W |  |
| Input | |
| Video Input | 5-ch |
| Max Resolution | 6MP |
| Two-way Audio Input | N/A |
| Bandwidth | Income 50Mbps; Outgoing 40Mbps |
| Output | |
| HDMI/VGA Output | HDMI 1-ch, 2560×1440, 1920×1080, 1280×720, 800×600, 1024×768, 1366×768, 1440×900, 1280×800 |
| VGA 1-ch, 1920×1080, 1280×720, 800×600, 1024×768, 1366×768, 1440×900, 1280×800 | |
| Screen Split | 1/3/4/5/6 |
| Audio Output | 1×RCA |
| Decoding | |
| Decoding Format | S 265/H.265/H.264 |
| Recording Resolution | 6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Preview Capability | 1×6MP, 1×5MP, 1×4MP, 1×3MP, 4×1080P, 5×720P, 5×4CIF |
| Synchronous Playback | 1×6MP, 1×5MP, 1×4MP, 1×3MP, 3×1080P, 4×720P |
| Records Encryption | Yes |
| Hard Disk | |
| SATA | 1 SATA interface for 1 HDD |
| Capacity | Up to 10TB for each HDD |
| eSATA Interface | N/A |
| Array Type | N/A |
| Wi-Fi | |
| Wireless Standards | IEEE802.11b/g/n |
| Frequency Band | 2.4GHz |
| Channel Bandwidth | 20/40MHz |
| Protocols | DSSS (DBPSK, DQPSK, CCK) OFDM (BPSK, QPSK, 16-QAM, 64-QAM) |
| Security | WPA/WPA2, WEP, TKIP and AES |
| Transfer Rates | 802.11b: 11Mbps 802.11g: 54Mbps 802.11n: Up to 150Mbps |
| Wireless Range | Up to 50 m (The performance varies based on actual environment) |
| Power Consumption | 802.11b: 18dBm@11Mbps 802.11g: 16dBm@54Mbps 802.11n: 16dBm@150Mbps |
| External Interface | |
| Network Interface | 1xRJ45 self-adaptive 10/100 Mbps network interface |
| USB Interface | 2xUSB 2.0 |
| Serial Interface | N/A |
| Alarm In/Out | N/A |
| Network | |
| Protocol | TCP/IP, ICMP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, QoS, IPV4, IPV6, Multicast, ARP, UDP, Telnet, RTMP |
| System Compatibility | ONVIF (PROFILE S/T), SDK, CGI, P2P |
| General | |
| Web Version | Web6 |
| Language | Traditional Chinese, English |
| Operating Conditions | -10℃～55℃, 10%~90% RH |
| Power Supply | DC12V 3.33A |
| Consumption (without HDD) | ≤18W (without HDD) |
| Chassis | 1U |
| Dimensions | 45×255×250mm, (1.77×10.04×9.84 inch) |
| Weight (without HDD) | 0.86Kg (1.9lb) |
